Elliott Cutters
1 / 5
Core Features: Multilayer structure of diamond and transition layer, improving impact resistance greatly. Best alternative for roller cone applications.
Applicable Position: Priority for rear row teeth, auxiliary for main teeth in soft to medium-hard formations. Buffers impact and protects main cutting parts.
Core Features: Flat, smooth tooth surface with large contact area. Delivers high cutting efficiency and outstanding wear resistance. High processing precision and wide adaptability.
Applicable Position: Priority for main teeth. Crushes formation rocks quickly. Can also be used as rear row teeth for auxiliary cutting and gauge protection.
Core Features: Sharp tapered tip with extremely strong penetration. Reduces drilling resistance in medium-hard to hard formations. Disperses stress effectively to avoid chipping.
Applicable Position: Main teeth only. Optimized for hard formation crushing where sharp penetration is required.
| Model No. | Diameter (mm) | Total Height (mm) | Diamond Thickness (mm) | Chamfer (mm) |
|---|---|---|---|---|
| S1308 | 13.44 | 8.00 | 2.00 | 0.40 |
| S1313 | 13.44 | 13.20 | 2.00 | 0.40 |
| S1316 | 13.20 | 15.88 | 2.00 | 0.35 |
| S1613 | 15.88 | 13.20 | 2.40 | 0.40 |
| S1913 | 19.05 | 13.20 | 2.40 | 0.30 |
| DE1319 | 12.925 | 19.00 | 4.60 | 5.94 |
| DE2028 | 20.00 | 28.00 | 5.40 | 11.0 |
