Elliott Cutters
1 / 4
Core Features: Consist of multilayer structure of diamond and transition layer, improving impact resistance greatly. The best alternative to be applied in roller cone bits.
Applicable Bit Position: Priority for rear row teeth. As rear row teeth, it buffers impact and protects main teeth from gravel damage.
Core Features: Large contact area delivering high cutting efficiency and outstanding wear resistance. High processing precision and high cost performance.
Applicable Bit Position: Priority for main teeth. Crushes formation rocks quickly; also suitable for rear row teeth to extend bit life.
Core Features: Sharp tapered tip with extremely strong penetration, reducing drilling resistance in medium-hard to hard formations. Excellent impact toughness.
Applicable Bit Position: Exclusively for main teeth. Sharp penetration advantage is ideal for hard formation crushing.
| Model No. | Diameter (mm) | Total Height (mm) | Diamond Thickness (mm) | Chamfer (mm) |
|---|---|---|---|---|
| S1308 | 13.44 | 8.00 | 2.00 | 0.40 |
| S1313 | 13.44 | 13.20 | 2.00 | 0.40 |
| S1613 | 15.88 | 13.20 | 2.40 | 0.40 |
| S1916 | 19.05 | 16.00 | 2.40 | 0.30 |
| DE1319 | 12.925 | 19.00 | 4.60 | 5.94 |
| DE2028 | 20.00 | 28.00 | 5.40 | 11.0 |
